NDV (Nippon Daiya Valve) provides high quality Diaphragm Valves, Ball Valves.
Nippon Daiya Valve offers ball and other valves in addition to our main product, the diaphragm valve, that meet the various needs of our customers with highly efficient, safe, and environmentally considerate products. Our valves are used across a broad range from chemical, environmental and water treatment services, iron and steel, medical, and power industries and sectors.
NDV’s representative product, the diaphragm valve, is superior in “air-tightness,” “maintenance,” and “corrosion and chemical resistance.” We can adapt to many fields because we construct valves from a vast selection of materials to meet the requirements and composition of fluids, being superior in terms of cost performance as well. Made from the wealth of experience and achievements cultivated over a long history, our products offer peace of mind with high quality and high performance.
NDV offers ball valves compatible over a wide range of fields. Choose from our extensive line-up to meet your purpose from multi-way and v-port ball valves in addition to the standard fire safe type. We also take orders for special purpose valves used under high pressure, and those for shield machine and nuclear power plants.
WE HAVE NDV BALL VALVES STOCK IN THAILAND
2 – Way Ball Valve Type : F107NB
Body, Ball and Cap Material : SCS13A (Stainless Steel)
Stem and Stud Bolt Material : SUS304 (Stainless Steel)
Gasket and Packing Material : PTFE
Process Connection : JIS10K and ANSI 150 RF
Size : 15A to 100A and ½” to 4”
Can fine technical information catalog no. BE302-04 at page no. 7, 8, 9, 10, 12, 13 and 14.
2 – Way Ball Valve Fire Safe Type : F100NB
Body, Ball and Cap Material : SCS13A (Stainless Steel)
Stem and Stud Bolt Material : SUS304 (Stainless Steel)
Gasket and Packing Material : PTFE
Process Connection : JIS10K and ANSI 150 RF
Size : 15A to 100A and ½” to 4”
Can fine technical information catalog no. BE302-04 at page no. 7, 8, 9, 10, 12, 13 and 14.
For the Pneumatically Actuator type, we do have stock of actuator for fitting the about size.
And we can do the assembling Ball valve with pneumatics actuator.
WE HAVE NDV MANUALLY OPERATED DIAPHRAGM VALVES STOCK IN THAILAND
Weir Type Diaphragm Valve : Type 400
Body Material : SCS13A and Hard Natural Rubber lined
Diaphragm Material : Natural rubber, Chloroprene rubber, EPDM & New PTFE+EPDM
Process Connection : JIS10K and ANSI 150 RF
Size : 15A to 100A and ½” to 4”
Can fine technical information catalog no. DE303-03 at page no. 6, 8, 10, 11, 12, 13 and 14.
WE HAVE NDV PNEUMATICALLY OPERATED TYPE ON-OFF DIAPHRAGM VALVES STOCK IN THAILAND
Weir Type Diaphragm Valve : Type PO(PC, PN)/ HO(HC, HN) 1400N
Body Material : SCS13A and Hard Natural Rubber lined
Diaphragm Material : Natural rubber, Chloroprene rubber, EPDM & New PTFE+EPDM
Process Connection : JIS10K and ANSI 150 RF
Size : 15A to 100A and ½” to 4”
Can fine technical information catalog no. DE303-03 at page no. 18, 19, 20, 21, 22, and 23.
|
